PRL Motorsports Short Ram Air Intake System Honda CR-V 1.5L Turbo 2017-2022

PRL Motorsports Big Bore MAF Housing Short Ram Air Intake System (PRL-HC10-INT-SRI-C)

The PRL-HC10-INT-SRI-C is engineered specifically for the 1.5L Turbo Honda Civic platform, offering a robust alternative for those who prefer a short ram intake system over a cold air intake. This system is designed to optimize airflow while maintaining factory-spec fuel trims, ensuring reliable drivability and performance.

Key Features

• MAF Housing: CNC machined billet aluminum construction, available in two configurations: Standard Bore and Big Bore.
• Air Filter: Equipped with a 4-inch air filter that promotes maximum airflow.
• Fuel Trims: The Standard Bore housing maintains factory fuel trims without tuning (-4% of factory STFT & LTFT), while the Big Bore housing increases airflow by 50%, requiring a tune for optimal performance.

Performance Gains

• Standard Bore MAF housing: Up to 15 horsepower and 12 ft/lb torque gains compared to stock without a tune.
• Big Bore MAF housing: Up to 20 horsepower and 15 ft/lb torque gains with a Big Bore MAF basemap calibration on Hondata and/or KTuner.
• Custom tuning can yield even larger gains at higher power levels.

Fitment

• Honda Civic Non-Si 1.5L Turbo (2016-2021)
• Compatible with various models including 6MT, CVT, RHD, and international variants.

Installation Notes

• Short ram intakes may be susceptible to heat-soak in this chassis, which is a key reason why a cold air intake is often recommended for optimal performance.
• For those looking to switch between MAF housings, a MAF Housing Conversion Kit is available, allowing for easy transitions without the need to purchase an entirely new intake system.
• A Cold Air Intake Conversion Kit is also available for those who wish to upgrade to a cold air setup in the future.

With the PRL-HC10-INT-SRI-C, you can enhance your Civic's performance while enjoying the flexibility of adjustable MAF housing options tailored to your tuning preferences.
